EX Series
//
Triple 8" Coaxial loudspeaker
The EX Series delivers high output, precision coverage, and clarity from a compact coaxial loudspeaker. Designed for immersive and nearfield applications, it excels where vertical control and space efficiency are essential.
TQ™ Processing
Optional Weather Resistance
Products in this Series
EX8
Triple 8” Coaxial Loudspeaker
Operating Range
72 Hz to 20 kHz
HF/LF Transducers
Coaxial 3.0″ titanium diaphragm compression driver; 12.0″ woofer, 3.0″ voice coil; single neodymium magnet
Power Handling at Nominal Impedance
HF/LF 400 W @ 8 Ω
Equalized Maximum SPL (peak / continuous)
128 dB / 122 dB
