FH Series
//
Full-Range, 2-Way, High-Sensitivity Coaxial Horn System
The FH Series delivers high-output, full-range performance and directional control from a single amplifier channel. Its arrayable coaxial horn design provides consistent pattern control in a compact, efficient enclosure.
TQ™ Processing
Arrayable
Optional Weather Resistance
Products in this Series
FH15
Full-Range Coaxial Horn
Available Coverage Patterns
60° x 45°, 60° x 60°, 90° x 45°, or 90° x 60°
Operating Range
54 Hz to 20 kHz
LF Transducers
1x 15.0 inch neodymium magnet cone driver, 3.5 inch voice coil
HF Transducers
4.0 inch titanium diaphragm, neodymium magnet compression driver
Power Handling at Nominal Impedance
HF/LF 800 W @ 8 Ω
Equalized Maximum SPL (peak / continuous)
139 dB / 133 dB
Dimensions (H x W x D)
29.89 in x 30.00 in x 28.00 in (759 mm x 762 mm x 711 mm)
Weight
107.0 lbs (48.5 kg)
